As a musician who has amassed a collection of musical instruments and noise boxes, the humble Arduino is the perfect tool to create a custom MIDI controller. Whilst the Raspberry Pi may have taken the crown for Internet of Things (IoT) The Internet of Things: 10 Useful Products You Must Try in 2016 The Internet of Things: 10 Useful Products You Must Try in 2016 The Internet of Things is ramping up in 2016, but what does that mean exactly? How do you personally benefit from the Internet of Things? Here are a few useful products to illustrate. Read More projects, a simple Arduino Uno (what are the different types of Arduino? Arduino Buying Guide: Which Board Should You Get? Arduino Buying Guide: Which Board Should You Get? There are so many different kinds of Arduino boards out there, you'd be forgiven for being confused. Which should you buy for your project? Let us help, with this Arduino buying guide! Read More ) has more than enough power for this project.

First time using an Arduino? No worries, we’ve got a complete Arduino beginner’s guide Getting Started With Arduino: A Beginner's Guide Getting Started With Arduino: A Beginner's Guide Arduino is an open-source electronics prototyping platform based on flexible, easy-to use hardware and software. It's intended for artists, designers, hobbyists, and anyone interested in creating interactive objects or environments. Read More to read through before you tackle this project.

Arduino-Midi-Controller-Breadboard

What is MIDI?

MIDI stands for Musical Instrument Digital Interface. It outlines a standard way for musical devices to communicate with each other. If you own an electronic keyboard you probably have a MIDI interface. Whilst there are a few technical details involved in the implementation of MIDI, it’s important to remember that MIDI is not audio! MIDI data is a simple set of instructions (one instruction is called a “message”) that another device may implement to make different sounds or control parameters.

MIDI supports 16 channels. This means that each cable can support 16 different devices communicating independently with each other. Devices are connected using a 5-pin DIN cable. DIN stands for “German Institute for Standardization”, and is simply a cable with five pins inside the connector. USB is often used in place of 5-pin DIN, or a USB-MIDI interface can be used.

MIDI-Cable-Male

Ads by Google

Control Change and Program Change

There are two main types of MIDI message: Control Change, and Program Change.

Control Change (CC) messages contain a controller number and a value between 0 and 127. CC messages are often used to change settings such as volume or pitch. Devices that accept MIDI should come with a manual explaining what channels and messages are setup by default, and how to change them (known as MIDI mapping).

Program Change (PC) messages are simpler than CC messages. PC messages consist of a single number, and are used to change the preset or patch on a device. PC messages are sometimes known as “Patch Change”. Similar to CC messages, manufacturers should provide a document outlining what presets are changed by a particular message.

What You Will Need

  • Arduino
  • 5-pin DIN female socket
  • 2 x 220 ohm resistors
  • 2 x 10k ohm resistors
  • 2 x momentary switches
  • Hook-up wires
  • Breadboard
  • MIDI cable
  • MIDI device or USB interface
Water & Wood 5 Pcs DIN 5 Pin PCB Mounting Female Sockets for PC Keyboard Water & Wood 5 Pcs DIN 5 Pin PCB Mounting Female Sockets for PC Keyboard 5 Pcs DIN 5 Pin PCB Mounting Female Sockets for PC Keyboard Buy Now At Amazon $3.23

Build Plan

This project will be quite simple. You can of course add more buttons or hardware to suit your needs. Almost any Arduino will be suitable — only three pins are needed for this example. This project consists of two buttons to control the program, a MIDI port to send the data, and a device to receive the messages. This circuit has been built on a breadboard Beginner's Electronics: 10 Skills You Need to Know Beginner's Electronics: 10 Skills You Need to Know Many of us have never even touched a soldering iron - but making things can incredibly rewarding. Here's ten of the most basic DIY electronics skills to help you get started. Read More here, however it is possible to transfer it to a project box and soldered connectors for a robust solution.

Circuit Assembly

Arduino-Midi-Controller-Circuit

MIDI Connection

MIDI-Pinout

Wire up your MIDI socket as follows:

  • MIDI pin 5 to Arduino Transmit (TX) 1 via a 220 ohm resistor
  • MIDI pin 4 to Arduino +5V via a 220 ohm resistor
  • MIDI pin 2 to Arduino ground

Button Connection

The buttons work by changing the resistance the Arduino “sees”. The Arduino pin goes through the switch straight to ground (LOW) via a 10k ohm resistor (a “pull down” resistor, ensuring the value stays low). When the button is pressed, the value seen by the circuit changes to +5v without a resistor (HIGH). The Arduino can detect this change using the digitalRead(pin) command. Connect the buttons to pins 6 and 7 on the Arduino digital input/output (I/O). Connect both buttons:

  • Left side of button to +5V
  • Right side of button to Arduino Ground via a 10k ohm resistor
  • Right side of button to Arduino pin (6 or 7)

MIDI Testing

Now that all the hardware is finished, it’s time to test it. You will need a USB-MIDI interface (many audio interfaces can do this) and a MIDI cable. The MIDI port wired up on the breadboard is sending data, so it is the output. Your computer is receiving the data, therefore it is the input. This project uses the excellent Arduino MIDI Library v4.2 by Forty Seven Effects. Once you have installed the Library, you can include it in your code by going to Sketch > Include Library > MIDI.

You’ll also need a program to monitor the incoming MIDI data:

Connect the Arduino Getting Started With Your Arduino Starter Kit - Installing Drivers & Setting Up The Board & Port Getting Started With Your Arduino Starter Kit - Installing Drivers & Setting Up The Board & Port So, you’ve bought yourself an Arduino starter kit, and possibly some other random cool components - now what? How do you actually get started with programming this Arduino thing? How do you set it up... Read More to your computer and upload the following test code (don’t forget to select the correct board and port from the Tools > Board and Tools > Port menus).

#include <midi.h>
#include <midi_defs.h>
#include <midi_message.h>
#include <midi_namespace.h>
#include <midi_settings.h>

MIDI_CREATE_INSTANCE(HardwareSerial,Serial, midiOut); // create a MIDI object called midiOut

void setup() {
  Serial.begin(31250); // setup serial for MIDI
}

void loop() {
  midiOut.sendControlChange(56,127,1); // send a MIDI CC -- 56 = note, 127 = velocity, 1 = channel
  delay(1000);  // wait 1 second
  midiOut.sendProgramChange(12,1); // send a MIDI PC -- 12 = value, 1 = channel
  delay(1000);  // wait 1 second
}

This code will send a CC message, wait 1 second, send a PC message then wait 1 second indefinitely. If everything is working correctly you should see a message appear in your MIDI monitor.

If nothing happens, don’t panic! Try troubleshooting:

  • Ensure all the connections are correct
  • Check the MIDI port is wired correctly – there should be 2 spare pins on the outside edges
  • Double-check the circuit is correct
  • Verify the circuit is connected to a USB-MIDI interface with a MIDI cable
  • Check your MIDI cable is connected to the input on your USB-MIDI interface
  • Make sure the Arduino has power
  • Install the correct driver for your USB-MIDI interface

If you are still having problems it might be worth checking your breadboard. Cheap boards can sometimes be very inconsistent and low-quality — it happened to me whilst working on this project.

Button Testing

Now it’s time to test the buttons are working correctly. Upload the following test code. MIDI does not need to be connected to test this part.

const int buttonOne = 6; // assign button pin to variable
const int buttonTwo = 7; // assign button pin to variable

void setup() {
  Serial.begin(9600); // setup serial for text
  pinMode(buttonOne,INPUT); // setup button as input
  pinMode(buttonTwo,INPUT); // setup button as input
}

void loop() {

  if(digitalRead(buttonOne) == HIGH) { // check button state
    delay(10); // software de-bounce
    if(digitalRead(buttonOne) == HIGH) { // check button state again
      Serial.println("Button One Works!"); // log result
      delay(250);
    }
  }

  if(digitalRead(buttonTwo) == HIGH) { // check button state
    delay(10); // software de-bounce
    if(digitalRead(buttonTwo) == HIGH) { // check button state again
      Serial.println("Button Two Works!"); // log result
      delay(250);
    }
  }

}

Run this code (but keep the USB cable connected) and open the Serial Monitor (Top Right > Serial Monitor). When you press a button you should see “Button One Works!” or “Button Two Works!” depending on the button you pressed.

There is one important note to take-away from this example – the software de-bounce. This is a simple 10 millisecond (ms) delay between checking the button and then checking the button again. This increases the accuracy of the button press and helps prevent noise triggering the Arduino. You do not have to do this, although it is recommended.

Creating the Controller

Now that everything is wired and working, it’s time to assemble the full controller.

This example will send a different CC message for each button that is pressed. I’m using this to control Ableton Live 9.6 on OS X. The code is similar to both the testing samples above.

#include <MIDI.h>
#include <midi_Defs.h>
#include <midi_Message.h>
#include <midi_Namespace.h>
#include <midi_Settings.h>

const int buttonOne = 6; // assign button pin to variable
const int buttonTwo = 7; // assign button pin to variable

MIDI_CREATE_INSTANCE(HardwareSerial,Serial, midiOut); // create a MIDI object called midiOut

void setup() {
  pinMode(buttonOne,INPUT); // setup button as input
  pinMode(buttonTwo,INPUT); // setup button as input
  Serial.begin(31250); // setup MIDI output
}

void loop() {
  if(digitalRead(buttonOne) == HIGH) { // check button state
    delay(10); // software de-bounce
    if(digitalRead(buttonOne) == HIGH) { // check button state again
      midiOut.sendControlChange(56,127,1); // send a MIDI CC -- 56 = note, 127 = velocity, 1 = channel
      delay(250);
    }
  }

  if(digitalRead(buttonTwo) == HIGH) { // check button state
    delay(10); // software de-bounce
    if(digitalRead(buttonTwo) == HIGH) { // check button state again
      midiOut.sendControlChange(42,127,1); // send a MIDI CC -- 42 = note, 127 = velocity, 1 = channel
      delay(250);
    }
  }
}

Note — you will not be able to use Serial.println() with MIDI output.
If you wanted to send a PC message instead of a CC simply replace:

midiOut.sendControlChange(42,127,1);

With:

midiOut.sendProgramChange(value, channel);

In Action

Below is a demonstration as a controller for Ableton Live (Best DJ software for every budget The Best DJ Software For Every Budget The Best DJ Software For Every Budget Good mixing software can make all the difference in your performance. Whether you're using a Mac, Windows, or Linux, every level of skill and budget is catered for if you want to start DJing. Read More ). The top right shows the audio meters, and the top middle shows the incoming midi messages (via MIDI Monitor on OS X).

Have you Made a MIDI Controller?

There are a lot of practical uses for a custom MIDI controller. You could build a vast foot-controlled unit, or a sleek studio controller. Have you made a custom MIDI controller? Let me know in the comments, I’d love to see them!
